流水线设备效果图种类繁多，根据不同的分类标准，可以将其归纳为以下主要类型：

皮带机流水线（效果图又称皮带输送机效果图）‌：

应用于电子、五金、食品、医药、物流中心及轻载物品的输送。

特点：运行平稳，噪音小，适用于轻型物料的长距离平稳输送。

滚筒机流水线效果图（又称辊道输送机效果图）‌：

应用于纸箱、周转箱、托盘、栈板等，适合底面是平面的物料输送，物流中心常用。

特点：承载的产品类型广泛，所受限制少，可配合阻挡器实现产品积放或离线检测。

链板机流水线效果图（又称板链输送机效果图、搁板输送机效果图）‌：

应用于大件物品且有一定重量的产品装配及输送要求，柔性链板则用于食品医药卷烟行业和物流中心。

特点：可承载比较重的产品，和生产线同步运行，可以实现产品的爬坡和平稳输送。

倍速链流水线效果图（又称倍速链输送机效果图、差速链输送机效果图）‌：

应用于大物件产品需要自由装配，柔性要求比较高的情况下。

特点：采用倍速链牵引，工装板可以自由传送，便于集成自动化设备，实现工件的自由运动或停止。

悬挂链流水线效果图（又称悬挂链输送机效果图）‌：

应用于物料的配送、储存、喷涂、烘干固化、利用高空间区域等情况下。

特点：以悬挂的方式完成产品的输送，常与链板输送线一起应用于汽车制造等行业。

链条式流水线效果图（又称链条式输送机效果图、栈板输送机效果图、托盘输送机效果图）‌：

适用于需要精确控制物料位置的场景。

特点：承载能力强，运行稳定。

桁架式流水线效果图（又称桁架输送机效果图）‌：

主要应用于汽车整车装配厂。

特点：结构稳固，承载能力强，适用于大型物件的输送。

雪橇式流水线效果图（又称雪橇输送机效果图）‌：

主要应用于汽车整车装配厂。

特点：输送效率高，适用于连续、大批量的生产。

轨道式流水线效果图（又称环形台车输送机效果图、循环式输送机效果图、往返式输送机效果图）‌：

应用于大型自动化仓储物流分拨中心，作为快速储存或配送周转来应用。

特点：输送能力强，运行平稳，适用于自动化仓储物流系统。
